Advanced ASI BAC855 Motor Controller

ASI BAC855 Advanced Motor Controller

This controller is commonly utilized for upgrades in systems like the BBSHD, Cyclone Mid Drive Motor Kit, Stealth Enduro Style EBikes, and various others. It's equipped to accommodate a torque sensor and employs FOC (Field Oriented Control) in its control algorithm, ensuring remarkably smooth and highly efficient performance. Despite its compact size, it boasts impressive power capabilities. These controllers offer an exceptionally smooth ride!

Please note: These controllers require setup for the motor by our team. Simply sending you a controller won't suffice; it needs to be programmed for your specific motor. This can be done remotely, but please reach out to us before making a purchase.

While these controllers are ideal for custom projects, if you're seeking the most budget-friendly option to get your EBike up and running, these are considered a premium product.

For inquiries, feel free to reach out to us at AffordableEBikes@gmail.com.

Key Details from ASI's website:

Power: 800 Watts

Nominal Voltage: 36 - 72V Volts

Nominal Current: 70 Amps

Peak Current: 90 Amps

CAN BUS: Yes

Auto Tuning: Yes

Sensorless Start: Adaptive

IP Rating: IP65 (IP67 with sealed connectors)

Quality Control Verification: 100% EOL Test under load

Additional Available Protocols: TTL 485, Bluetooth, LIN, CAN
